Nortel 1110 IP Phone (NTYS02)

The Nortel 1110 IP Phone (NTYS02) is a reliable single-line VoIP business telephone designed for users who require essential IP telephony features in a compact and cost-effective desktop device. Featuring a backlit LCD display, programmable soft keys, integrated Ethernet switch, and Power over Ethernet (PoE) support, the 1110 IP Phone delivers dependable voice communications for offices, reception areas, and shared workspaces.

Its integrated LAN and PC ports help reduce network infrastructure costs while providing a simple deployment solution for Nortel IP telephony environments.

Features

• Single-line IP phone
• 143 x 32 pixel monochrome backlit LCD display
• 8 fixed feature keys
• 4 programmable soft keys
• Navigation cluster
• Integrated Ethernet switch
• LAN and PC ports
• Field-upgradable firmware via TFTP
• Five-position adjustable stand
• Power over Ethernet (PoE) support
• Includes 1-Year Warranty

Specifications

• Display:
  • 143 x 32 Pixel Monochrome Backlit LCD
• Phone Type:
  • Single-Line IP Phone
• Keys:
  • 8 Fixed Feature Keys
  • 4 Soft Keys
• Navigation:
  • Navigation Cluster
• Network:
  • Integrated Ethernet Switch
  • LAN Port
  • PC Port
• Firmware:
  • Field-Upgradable via TFTP
• Power:
  • IEEE 802.3af Power over Ethernet (PoE)
  • Optional Local AC Power Supply (Sold Separately)
• Codecs:
  • G.711a/u
  • G.729a/b
• Protocol:
  • E.164 Dialing
• Color:
  • Graphite with Silver Bezel
• Dimensions:
  • 6.6″ x 7.3″ x 7.7″
• Weight:
  • 1.81 lbs.

Key Calling Features

• Single-Line VoIP Communications
• Soft Key Navigation
• IP Telephony Support
• Programmable Features
• Display-Based Call Information
• Directory Access
• Extension Dialing
• Network Connectivity Sharing

Display and Productivity Features

The backlit LCD display provides convenient access to:

• Call Information
• System Menus
• Feature Prompts
• Directory Information
• User Settings

The navigation cluster and soft keys allow users to quickly access frequently used telephone functions.

Network Connectivity

The integrated Ethernet switch allows both the phone and a desktop PC to share a single network connection.

Benefits include:

• Reduced cabling requirements
• Simplified installations
• Lower deployment costs
• Efficient desktop connectivity

Compatibility

Compatible with:

• Nortel Communication Server 1000 Release 4.0 or Later
• Nortel Communication Server 2000 SN09U-MR7 or Later
• Nortel Communication Server 2100 SE10 or Later
• Nortel Media Gateway 1000B Expansion Chassis

Ideal Applications

The Nortel 1110 IP Phone is ideal for:

• Office Professionals
• Reception Areas
• Administrative Staff
• Healthcare Facilities
• Educational Institutions
• Government Offices
• Shared Workspaces
• Retail Locations
• Small Businesses
• Enterprise Environments

Why Choose the Nortel 1110 IP Phone?

The Nortel 1110 IP Phone offers a cost-effective entry point into IP telephony while providing essential business communications features. Its backlit display, Ethernet switch, PoE support, and easy deployment make it a practical solution for organizations looking to expand or maintain their Nortel VoIP infrastructure.

Professionally Refurbished and Tested

Each Nortel 1110 IP Phone (NTYS02) is professionally refurbished, cleaned, tested, and inspected to help ensure reliable performance and functionality.

Package Includes

• Nortel 1110 IP Phone (NTYS02)
• 1-Year Warranty

Related Products

Browse our selection of Nortel IP phones, replacement handsets, accessories, VoIP equipment, and business communications solutions.

Documentation

Need setup and operating instructions for the Nortel 1110 IP Phone?

Download the Nortel 1110 User Guide for detailed information on installation, programming, and operation.
